Electric Tib Beam Crane

Electric Tib Beam Crane


Ib tus choj crane ib leeg yog ib qho nyiaj siv ua haujlwm crane uas siv ib leeg girder los txhawb nqa lub hoist thiab trolley. Lub girder yog txuas rau ob lub tsheb thauj khoom kawg uas tau muab tso rau ntawm lub log uas khiav raws txoj kab ciav hlau khiav. Hom crane no feem ntau yog siv rau hauv me me mus rau nruab nrab-qhov loj me factories, warehouses, thiab rhiav rau lifting thiab thauj loads.



Hluav taws xob ib leeg nqaj cranes muaj txiaj ntsig zoo thiab pheej yig. Lawv muaj qhov hnyav qis dua piv rau lwm cov nyiaj siv ua haujlwm cranes, uas ua rau lawv yooj yim rau nruab thiab yuav tsum muaj kev txhawb nqa tsawg dua. Lawv kuj tau yooj yim rau kev khiav lag luam thiab kev tswj xyuas, thiab cov nqi ntawm kev kho thiab kho cov nqi qis dua. Tsis tas li ntawd, lawv tau hloov pauv tau yooj yim hauv kev tuav ntau yam kev thauj khoom, ua rau lawv haum rau ntau yam kev siv.



Hluav taws xob ib nqaj cranes tuaj nyob rau hauv kev teeb tsa sib txawv nrog rau kev khiav saum toj, hauv qab khiav, thiab underslung. Sab saum toj khiav cranes yog hom siv ntau tshaj plaws nyob rau hauv kev lag luam chaw, qhov chaw uas lawv taug kev ntawm cov ntsia hlau ntsia ntawm qhov siab tshaj plaws ntawm lub tsev. Nyob rau hauv khiav cranes raug tshem tawm los ntawm lub hauv qab flange ntawm ib tug khiav beam thaum underslung cranes yog dai los ntawm lub tsev lub ru tsev qauv.

Tsim thiab tsim raws li tus qauv JB/T1306-2008, nws muaj cov yam ntxwv ntawm cov qauv tsim nyog thiab muaj zog rigidity ntawm tag nrho lub tshuab.

Lub tshuab tag nrho yog siv ua ke nrog CD1, MD1, HC thiab lwm hom hluav taws xob hoists.

Muaj ob lub tshuab hluav taws xob ua haujlwm ntawm nws tus kheej, uas tuaj yeem ua tiav kev nqa ntawm cov khoom ua haujlwm, thiab tuaj yeem koom tes nrog ib leeg los ua kom tiav cov haujlwm loj. Nyob rau tib lub sijhawm, txhua tus tswj tuav tuaj yeem tswj tus kheej tswj lub laub sib koom ua haujlwm.

Lub peev xwm nqa tau yog 1 ntxiv rau 1--16 ntxiv rau 16 tons, qhov siv tau yog 5-35 meters, qib ua haujlwm: A3, A4, thiab qhov chaw ua haujlwm nyob hauv thaj tsam ntawm -25 degree ~ ntxiv rau 40 degree.

Tag nrho cov kis tau tus mob txais yuav ib tug mos tsav lub cev muaj zog thiab ib tug reducer los xyuas kom meej nws tsis tshua muaj suab nrov thiab ruaj khov kev ua tau zoo.

Raws li qhov xav tau ntawm cov neeg siv khoom nyob rau ntawm qhov chaw ua haujlwm, nws tuaj yeem nruab nrog zaus hloov pauv ntawm lub laub, kev hloov pauv zaus ntawm kev nqa lossis ob-ceev hoist ua haujlwm, kom cov haujlwm ntawm crane (crane) ruaj khov thiab txhim khu kev qha.


Kev kho ntawm choj cranes


1) Cov tsos ntawm tus choj crane: ntxuav lub ntsej muag kom zoo, kom tsis muaj plua plav thiab tsis muaj lub tsho daj. Tshawb xyuas qhov tawg thiab qhib vuam.


2) Lub laub thiab trolleys: ① Txheeb xyuas thiab ceev lub rooj zaum kis tau tus mob, lub thawv iav, sib txuas, ncej thiab qhov tseem ceeb rau xoob; ② Tshawb xyuas thiab kho lub log tsheb tshem tawm kom nws txawm, rhiab thiab txhim khu kev qha.


3) Txheeb xyuas tus choj crane reducer feem ntau kom pom tias nws xau roj. Yog tias muaj suab txawv txav hauv lub thawv thaum lub sijhawm ua haujlwm, nws yuav tsum tau qhib lub thawv npog los xyuas. Feem ntau, nws yog tshwm sim los ntawm kev puas tsuaj, ntau dhau iav meshing backlash, hnyav hniav hnav thiab lwm yam laj thawj.


4) Lifting winch: ① Tshawb xyuas seb cov hlua khi hlua khi, hlua khi thiab rub lub cev puas muaj kev nyab xeeb thiab txhim khu kev qha, thiab hloov lawv yog tias hnav ntau tshaj li qhov teev tseg. ② Tshawb xyuas thiab kho tus nres kom nws muaj kev nyab xeeb, rhiab thiab txhim khu kev qha.


5) Kev tshuaj xyuas cov hlua hlau ntawm cov choj cranes. Feem ntau siv ntau yam xws li phosphating-coated steel hlau hlua, galvanized steel hlau hlua thiab du steel hlau hlua. Thaum kuaj xyuas cov hlua hlau hlau, koj yuav tsum tsom mus saib xyuas cov xov hlau tawg, hnav, kinks, thiab corrosion. cim, txhawm rau tsom rau kev taug qab rov qab tshuaj xyuas. Ua tib zoo xyuas seb qhov kev txwv kev nyab xeeb ntawm cov hlua hlau hauv lub nruas puas zoo, seb cov hlua hlau hlua ntawm lub nruas yog nias kom nruj thiab seb cov phaj siab puas tsim nyog.


6) Lubrication: Xyuas cov roj zoo thiab kom muaj nuj nqis ntawm txhua qhov chaw, thiab ntxiv lossis hloov cov roj lubricating raws li qhov xav tau.


7) Tshawb xyuas lub pulley ntawm tus choj crane. Kev tsom xam yog nyob ntawm seb qhov hnav hauv qab ntawm qhov zawj tshaj qhov qauv thiab seb puas muaj cov kab nrib pleb hauv cov cam khwb cia hlau rub. Rau qhov sib npaug lub log ntawm lub suab mechanism pulley thaiv, nws yog ib qho yooj yim kom tsis quav ntsej vim nws tsis txav mus rau hauv ib txwm muaj. Yog li ntawd, qhov yooj yim ntawm kev sib hloov yuav tsum tau kuaj xyuas ua ntej kev teeb tsa, txwv tsis pub, qhov ntev thiab qhov nro ntawm sab laug thiab txoj hlua hlau hlua thaum lub sijhawm teeb tsa tsis tuaj yeem hloov kho los ntawm lub log sib npaug, uas ua rau qhov nyuaj thiab txaus ntshai ntawm kev kho cov hlua ntawm qhov siab.


8) Hluav taws xob: ① Tshawb xyuas seb qhov kev txwv qhov hloov pauv puas muaj kev cuam tshuam thiab txhim khu kev qha; ③ Tshawb xyuas seb cov khoom siv hluav taws xob hauv lub thawv hluav taws xob puas muaj kev cuam tshuam thiab txhim khu kev qha; ③ Tshawb xyuas seb lub cav, lub tswb hluav taws xob, thiab cov xov hlau puas muaj kev nyab xeeb thiab txhim khu kev qha; ④

Xyuas seb lub teeb teeb pom kev zoo puas zoo.


9) Xyuas seb qhov txuas ntawm tus choj crane puas xoob lossis txawm tias "cov yuam sij dov". Tsom ntsoov rau kev tshuaj xyuas seb lub nplhaib roj hmab elastic ntawm lub elastic pin coupling yog txawv txav, thiab xyuam xim tshwj xeeb rau kev hnav ntawm lub nplhaib iav ntawm cov hniav sib txuas. Vim yog qhov tsis zoo ntawm kev txhim kho qhov tseeb, nyob rau hauv rooj plaub ntawm qhov kev sib hloov loj ntawm ob lub shafts, tag nrho lub nplhaib iav yuav hnav sai sai hauv lub sijhawm luv luv. Yog tias muaj qhov xwm txheej zoo li no hauv lub tshuab nqa, kev sib tsoo loj yuav tshwm sim.

Lifting Nyhav (t)	1				2				3				5				10				16				Customized
Ntev (m)	7.5	10	15	18	8	13	18	27	7.5	12	18	23	8	12	15	18	8	12	15	20	12	19	25	28	Customized
Ua hauj lwm ceev (m / min)	Hauv av 20								Hauv av 20								Hauv av 20				Hauv av 20				Customized
Hoisting Qhov siab (m) Customized	Customized
Chav Ua Haujlwm	A4 los yog Customized
Hluav taws xob tam sim no	Customized
